  #11
Unread 06-29-2018, 08:31 PM
dankerson's Avatar
dankerson dankerson is offline
SUPER BAT - $ Donating Member

Join Date: Oct 2005
Location: cali
Posts: 2,596
Default

Very cute my friend.
__________________
2000 Aprilia RS 50/TP85 cc stroker kit
2003 Derbi Super Motard with a CR85R race engine
2001 Honda RS 250R that beat my fastest times already
2006 Aprilia RS125 Street legal
4 2004 go-peds all with race engines
2017 Ford F2fity to haul all my bike with
Reply With Quote
  #12
Unread 06-30-2018, 03:44 PM
twinturba's Avatar
twinturba twinturba is offline
Moderator - $ Donating Member

Join Date: Oct 2005
Location: San Francisco
Posts: 935
Default

Had more time to spend on the Max yearly service today and am nearing completion!
Zapped the wheels off as I have brand new Mitas MC16 tires and aluminium valve stems witing to go on.

Front wheel needs a 19mm Zap


Rear wheel takes a 24mm Zap while holding the rear brake!


To get the rear wheel off as easily as possible the caliper and pipe need to come off. Nice that Aprilia Made access to the bolts easy, you can see the T handle fits under the airbox to access the top bolt.


Pipe off and wheel is ready to come off


Caliper set aside.


Needed to use something to hold up the front end after taking off the wheel, so the Bats box settles in



Wheels off and new tires and stems ready!


FYI, it’s reccomended to replace deez nutz that hold on the front and rear wheel after removal so I called my local Aprilia dealer to order.


Mounted the tire, installed the aluminum valve stem, and gave it a wipe down. Looks like new!


With the help of my son to lend a couple hands, I reinstalled the front wheel and new tire sans the nut.


With the rear wheel removed it was time to change the gear oil.


Drain bolt is so much easier to access with the rear wheel removed!


So is the fill hole and dipstick!


Original oil still looks ok!


Old oil out



Although the manual calls for 75/90 I’m going with some authentic racing oil from Honda 80/85W


Poured in exactly the same OZ’s as I drained out and checked the level after filled.


All done with the oil change and did a little wipedown, but I’m gonna need to do a full cleaning before reinstalling the rear wheel.


Almost done with the yearly maintenance!
__________________
Current:Newd, twinturba, Max, Bangkok, Derbi ADV

Past: NCXD, '16 & '15 RC390, '11 Madass,'12 PW50, KTM BR 65, Aprilia BR50, '06 & ‘98 Aprilia RS125, '04 DRD, 08 WR250X, 7x '03 Derbi SM's, 10x ‘99-‘04 Aprilia RS50's, 2x Derbi GPR, 2x Aprilia RS250, '95 & ‘00 Mito 125, '04 & '95 NSR50R, '90 NS50, '94 Honda RS125, '90 Honda RS80, '88 YSR63 (1st 2stroke!), '89FZ600, '89KLR250(1st Bike!)
Reply With Quote
  #13
Unread 07-12-2018, 10:54 AM
twinturba's Avatar
twinturba twinturba is offline
Moderator - $ Donating Member

Join Date: Oct 2005
Location: San Francisco
Posts: 935
Default

Had to finish up the service so I can start picking up my son at summer camp daily.
Did a little clean up on the drivetrain, it was a little grimey from picking up my son from school everyday, even in wet weather!



After clean up I got the rear wheel and brake cleaned up and reinstalled.



With all that back in place it was time for the Pipe clean up and reinstall.



With everything done, all that was left to do was reset the service light!



Ready for another year of Pickup Duty!

__________________
Current:Newd, twinturba, Max, Bangkok, Derbi ADV

Past: NCXD, '16 & '15 RC390, '11 Madass,'12 PW50, KTM BR 65, Aprilia BR50, '06 & ‘98 Aprilia RS125, '04 DRD, 08 WR250X, 7x '03 Derbi SM's, 10x ‘99-‘04 Aprilia RS50's, 2x Derbi GPR, 2x Aprilia RS250, '95 & ‘00 Mito 125, '04 & '95 NSR50R, '90 NS50, '94 Honda RS125, '90 Honda RS80, '88 YSR63 (1st 2stroke!), '89FZ600, '89KLR250(1st Bike!)
Reply With Quote
  #14
Unread 07-25-2018, 03:59 PM
dankerson's Avatar
dankerson dankerson is offline
SUPER BAT - $ Donating Member

Join Date: Oct 2005
Location: cali
Posts: 2,596
Default

I like the front tool box stand sticker placement. I'll remember that when I paint my race bike for those onboard shots.
__________________
2000 Aprilia RS 50/TP85 cc stroker kit
2003 Derbi Super Motard with a CR85R race engine
2001 Honda RS 250R that beat my fastest times already
2006 Aprilia RS125 Street legal
4 2004 go-peds all with race engines
2017 Ford F2fity to haul all my bike with
Reply With Quote
  #15
Unread 12-04-2018, 02:43 PM
twinturba's Avatar
twinturba twinturba is offline
Moderator - $ Donating Member

Join Date: Oct 2005
Location: San Francisco
Posts: 935
Default

I ride Max 5 days a week to pick up my son from school so I needed a solution for mounting my iPhone. With the unique experience of extended motorcycle travel I have found the Ram mounting system to be awesome, but their X-grip phone holder to be not so great. With this in mind I searched for other phone mounting solutions and found the Quad Lock system that utilizes a special protective case for the iPhone and a Jenius mounting system.

Searching on the interwebs revealed that some owners of SR50’s in Europe use the mirror as a mounting point for phones so I went ahead and ordered a few Ram Mount pieces to get the quad lock ball mount to work.

The left side mirror was my target for mount.


The parts I used for the mount.


Had to drill out the mounting hole with a 1/2” drill bit to allow it to slide over the mirror “bushing” and sit flush.


Also located a longer bolt to accomodate the height increase of the mirror. Stock on the left, new stainless on the right. 5mm more makes the difference.


All that was left was to put it all together.



And now in use!
